MINC I EURO VP 220009

The side-slip tester MINC I EURO ensures that the axle geometry is inspected within seconds once the test vehicle passes over it (up to 3.0 t axle load) as well as a fully automatic evaluation of the deviation in m/km. The display of the measurement values is either analogue via dial or via transmission to a PC screen (including graphic display).

product details / scope of delivery

Description:

  • Inspection of axle geometry in a matter of seconds upon drive-on
  • Fully automatic analysis of variation in m/km
  • In conjunction with EUROSYSTEM: display on PC screen with measurement visualisation and graphic representation
  • In conjunction with LON brake testers: illustration of measurements on dial analogue displays
  • Varnished with high-quality powder coating: anthracite grey, RAL 7016


Standard Delivery:

  • Side Slip Tester MINC I EURO FloorAssembly
  • Pre-configured for connection to EUROSYSTEM or LON test line
  • Pre-configured for stand-alone use (requires MCD 2000 communication desk with electronics)

Downloads

Sales documents

Technical Datasheet
Technical Datasheet MINC I EURO
DE EN
Technical Datasheet (Printable version) MINC I EURO
DE EN

Technical Data

Technical Data:

Axle load3000 kg
Measurement range+/- 20 m/km
Drive-over speed5 - 7 km/h
Floor assembly dimensions (H x W x L)80 x 1020 x 460 mm
